| Classification | E 30 EW 30 with CE according to EN 16034, VKF approval for Switzerland #31653 |
| System size | max. 4400 x 4470 mm, depends on type |
The fire curtain system Fire PROtec² will start a new generation of textile smoke and fire protection. It is just as flexible as the certified smoke and fire protection qualities of the harmonised standard EN 16034.
We incorporated the expertise of our product development as well as the production with regard to smoke ventilation actuators into the new FSV2 (project name). Thus, the production of serial and project parts could be significantly enhanced. Compared to its precursor, the new system complies with the requirements of EN 16034 from the very beginning. As of now, it can be labelled with a declaration of performance CE in the direct and extended area of application. At the same time, this is your proof of usability for integrating the system in your building project.
The fire curtain system Fire PROtec² is offered in two versions:
Limited heat radiation for more than 30 minutes: Fire PROtec² EW30-C2
The fire curtain system EW30-C2 is wall mounted on the side facing the fire. Developing the Fire PROtec² EW30-C2, the main focus was to keep the headboxes small (150x182 mm with a maximum curtain size of 2.80 x 3 m and 180x212 for max curtain size of 4.40 x 4.47 m) and the visual quality high. The curtain will be delivered as a construction kit and can be mounted and installed easily which saves both time and money. Especially the "snap-in" mechanism considerably facilitates the installation of the pre-fabricated roller unit. As for the control units, SIMON PROtec offers two possibilities (with and without emergency power, + emergency open) with an approved locking panel RZ-24.
The whole system can be used for outside application if equipped with a heating system and a weather protection shield.
| Matchcode | FSV2-EW30 |
| Product name | Fire Curtain Fire PROtec² EW 30 |
| Features | CURTAINS |
| Classification | E 30 EW 30 with CE according to EN 16034, VKF approval for Switzerland #31653 |
| Fabric | Fire retardant polyurethane coated e-glass fabric in grey 690 g/m² (A2 | EN 13501-1) |
| Unwind | descending by gravity (gravity fail safe) |
| Rewind | planetary gear motor, 24 V DC, 3 A with electric overload cut-off; roll shaft-integrated. |
| System installation | Ceiling / wall with appropriate approved mounting material |
| System size | max. 4400 x 4470 mm, depends on type |
| Housing | Head box (W x H): Galvanized sheet steel 1.5 mm (150 x 182 mm or 180 x 212 mm for drop over 3 m); Side guides (W x H): Galvanized sheet steel 2 mm (58 x 95 mm) |
| Bottom Bar | Galvanised steel 2 mm with integrated springs and round steel in fabric bag for gravity fail-safe |
| Part no. | Matchcode | |
|---|---|---|
| FSV2 2011 | FSV2-182-SFS-EW30 | |
| FSV2 2012 | FSV2-182-XL-SFS-EW30 | |
| FSV2 2013 | FSV2-212-SFS-EW30 | |
| FSV2 2014 | FSV2-212-XL-SFS-EW30 | |
 Brochure FSV + RSV | Brochure about the fire protection curtains and smoke protection curtains |
| Mounting guide Fire PROtec² | for the mechanical mounting |
| Operating Manual PROtec RZ-24 | Operating manual for the hold-open system PROtec RZ-24 for holding open and closing a textile fire curtain. |
| Control unit PROtec-RZ-24 | Schematics für CE purpose |
| Control unit PROtec-RZ-24-SB | Schematics for CE purpose with emergency power |
| CAD FireProtec² | CAD FireProtec² |
| CE Certificate_FSV2_DE-EN-FR | CE Certificate for the fire protection curtain FSV2 |
| Declaration of Performance Fire PRotec² EW30 | Declaration of Performance Fire PRotec² EW30 (Draft) |
| Project data for FSV² | Project data for FSV² |
| Safety instructions and warranty conditions | Safety instructions and warranty conditions |
